Welcome to Flux Hydraulic Masters! Feel free to check out our range of high-quality master cylinders, with their superior design and lifetime warranty.
Flux Hydraulic Masters™
Specialist range of performance brake master cylinders!
Backed by decades of industry knowledge and experience. Taking pride in getting all the details right, the Flux master cylinders feature a durable black E-coating, high pressure die cast aluminium design and superior quality EPDM rubber seals. With our design engineered for both safety and performance, we can guarantee you'll get the BEST out of Flux hydraulic master cylinders.
Servicing
- Flux hydraulic masters are rebuildable using our rebuild kits, ensuring low cost and easy mantinance
Hydraulic fliud compatability
- Compatible with standard DOT3, DOT4 and DOT5.1 Glycol Ether based brake fluids
Sizes
- We produce a range of masters to suit 3/4", 5/8" & 7/8"
Reservoir variants
- Available in both intergral and inline reservoir variants
Product range
Internal reservior master cylinders
FL-IR-34 internal reservior 3/4
Internal reservior master cylinder specifications
- Bore size
- 0.75 (3/4")
- Stroke
- 1.25
- Area(in²)
- 0.44
- Volume(cu in)
- 0.55
- Type
- Single outlet
- Outlets
- 1
- Material
- Aluminium
- Finish
- E-coating Black
- Res type
- internal
- Inlet
- n/a
- Outlet
- 3/8-24
- Rod thread
- 5/16-24
- Bolt spacing
- 2-14"
FL-IR-58 internal reservior 5/8
Internal reservior master cylinder specifications
- Bore size
- 0.625 (5/8")
- Stroke
- 1.25
- Area(in²)
- 0.31
- Volume(cu in)
- 0.38
- Type
- Single outlet
- Outlets
- 1
- Material
- Aluminium
- Finish
- E-coating Black
- Res type
- internal
- Inlet
- n/a
- Outlet
- 3/8-24
- Rod thread
- 5/16-24
- Bolt spacing
- 2-14"
FL-IR-78 internal reservior 7/8
Internal reservior master cylinder specifications
- Bore size
- 0.88 (7/8")
- Stroke
- 1.25
- Area(in²)
- 0.60
- Volume(cu in)
- 0.75
- Type
- Single outlet
- Outlets
- 1
- Material
- Aluminium
- Finish
- E-coating Black
- Res type
- internal
- Inlet
- n/a
- Outlet
- 3/8-24
- Rod thread
- 5/16-24
- Bolt spacing
- 2-14"
Inline reservior master cylinders
FL-RR-34 inline reservior 3/4
Inline reservior master cylinder specifications
- Bore size
- 0.75 (3/4")
- Stroke
- 1.25
- Area(in²)
- 0.44
- Volume(cu in)
- 0.55
- Type
- Single outlet
- Outlets
- 1
- Material
- Aluminium
- Finish
- E-coating Black
- Res type
- inline
- Inlet
- 7/16-20
- Outlet
- 3/8-24
- Rod thread
- 5/16-24
- Bolt spacing
- 2-14"
FL-RR-58 inline reservior 5/8
Inline reservior master cylinder specifications
- Bore size
- 0.625 (5/8")
- Stroke
- 1.25
- Area(in²)
- 0.31
- Volume(cu in)
- 0.38
- Type
- Single outlet
- Outlets
- 1
- Material
- Aluminium
- Finish
- E-coating Black
- Res type
- inline
- Inlet
- 7/16-20
- Outlet
- 3/8-24
- Rod thread
- 5/16-24
- Bolt spacing
- 2-14"
FL-RR-78 inline reservior 7/8
Inline reservior master cylinder specifications
- Bore size
- 0.88 (7/8")
- Stroke
- 1.25
- Area(in²)
- 0.60
- Volume(cu in)
- 0.75
- Type
- Single outlet
- Outlets
- 1
- Material
- Aluminium
- Finish
- E-coating Black
- Res type
- inline
- Inlet
- 7/16-20
- Outlet
- 3/8-24
- Rod thread
- 5/16-24
- Bolt spacing
- 2-14"
Master cylinder Serviceability
Maintenance kit's
All Flux master cylinder's are rebuildable and can be serviced with our inexpensive rebuild kits, avaiable for all models.
Flux Hydraulic Masters™ Warranty
We have you covered!
We completely back ourselves and our product's offering a lifetime warranty on our master cylinders
If you would like to make a warranty claim, get in contact with us at [email protected]
